High Speed Boat Design Part 2-Wings
By Lohring Miller
NAMBA Safety Chairman
We discussed two things in the last section that greatly affect
the performance of fast boats, air lift and planing drag. This
article concentrates on wings. First, a brief explanation of the
forces on airfoils. The forces are calculated by the dynamic
pressure times an experimentally determined coefficient and the
surface area. The dynamic pressure is the density of the fluid (air
or water) times the speed squared. Because the speed is squared,
the force goes up very rapidly with an increase in speed. Note
also that water is 800 times as dense as air. That means that a
force on the same object in water is 800 times as strong as the
force on the same object at the same speed in air.
The coefficients mentioned above are the coefficient of lift,
drag, and moment. They are proportional to the lift, the force at
right angles to the flow direction; the drag, the force along the
flow; and the moment, the force rotating the airfoil. Multiplying
the coefficients by the surface area of the airfoil and the dynamic
pressure gives the actual force.
Understanding how to make air lift improve performance
requires understanding how airfoils work close to the ground.
Far from the surface, the low pressure created over the top of a
standard airfoil creates some of the lift. However, close to a
surface, the air compressed between the bottom of the airfoil and
the surface becomes more important. Let’s look at what happens
with a standard NACA 2412 airfoil. The pictures below are from
Martin Hepperle’s airfoil analysis tools for two dimensional flow
over the airfoil. Real flows are more complicated, but have
similar trends. The flow field pictures show the pressures over
the airfoil. Orange going to red shows increasing positive
pressure, and green going to blue shows increasing negative
pressure. I angled the airfoil so the bottom is close to parallel to
the ground. First the pictures show the airfoil well clear of any
surface.
